WESTWIND 19
Description
The WESTWIND 19 is a cruising yacht designed by Luger Boats. She combines good sailing performance with comfortable accommodations, The conservative sail plan ensures easy handling in all conditions. Designed for serious cruising, whether coastal hopping or ocean crossings.
Construction Details
| Designer | Luger Boats |
|---|---|
| Length | 19.000 ft |
| LOA | 37.920 ft |
| LWL | 33.000 ft |
| Beam | 12.000 ft |
| Displacement | 19200 lb |
| Max Draft | 4.920 ft |
The standard boat dimensions
| i | 19.50 ft |
|---|---|
| j | 5.17 ft |
| p | 23.50 ft |
| e | 12.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 19.50 ft | 5.17 ft | 23.50 ft | 12.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GENOA |
|---|---|
| Luff | * 19.17 ft - (5843 mm) |
| Foot | * 8.2 ft - (2499 mm) |
| Leech | * 18.25 ft - (5563 mm) |
| Percentage LP | * 150.1 % |
| Length Perpendicular | * 7.76 ft - (2365 mm) |
| Deck Angle | * 4.02 ° |
| Area | * 74.37 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 16.14 ft - (4919 mm) |
| Foot | * 6.67 ft - (2033 mm) |
| Leech | * 14.41 ft - (4392 mm) |
| Percentage LP | * 115.09 % |
| Length Perpendicular | * 5.95 ft - (1814 mm) |
| Deck Angle | * 12.03 ° |
| Area | * 48.01 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 23.5 ft - (7163 mm) |
| Foot | * 12.5 ft - (3810 mm) |
| Leech-AftHdBd | * 25.94 ft - (7907 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 26.23 ft - (7995 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 152.1 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 19.17 ft - (5843 mm) |
| MidGirth | * 9.31 ft - (2838 mm) |
| Foot | * 9.31 ft - (2838 mm) |
| Perc LP | * 180 |
| Area | * 152 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
