TRAVELLER 32
Description
The TRAVELLER 32 is a dinghy designed by Philip Rhodes. This nimble dinghy is designed for responsive sailing and easy handling, featuring variable draft for versatility in different sailing conditions. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Construction Details
| Designer | Philip Rhodes |
|---|---|
| Length | 32.000 ft |
| LOA | 19.690 ft |
| LWL | 17.220 ft |
| Beam | 8.040 ft |
| Displacement | 1521 lb |
| Max Draft | 4.560 ft |
| Min Draft | 0.790 ft |
The standard boat dimensions
| i | 41.50 ft |
|---|---|
| j | 15.50 ft |
| p | 37 ft |
| e | 15.17 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 41.50 ft | 15.50 ft | 37 ft | 15.17 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 35.44 ft - (10802 mm) |
| Foot | * 21.12 ft - (6437 mm) |
| Leech | * 29.98 ft - (9138 mm) |
| Percentage LP | * 114.97 % |
| Length Perpendicular | * 17.82 ft - (5432 mm) |
| Deck Angle | * 11.97 ° |
| Area | * 315.81 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 43 ft - (13106 mm) |
| Foot | 26 ft - (7925 mm) |
| Leech | 40 ft - (12192 mm) |
| Perc LP | * 165 |
| Area | * 838 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 37 ft - (11278 mm) |
| Foot | * 15.17 ft - (4624 mm) |
| Leech-AftHdBd | * 39.22 ft - (11954 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 39.5 ft - (12040 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 288.63 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 42.09 ft - (12829 mm) |
| Foot | * 25.55 ft - (7788 mm) |
| Leech | * 39.15 ft - (11933 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 23.25 ft - (7087 mm) |
| Deck Angle | * 4.01 ° |
| Area | * 489.32 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
