Tanzer 29
Description
The TANZER 29 is a compact cruiser designed by Joubert-Nivelt. She strikes a balance between performance and comfort, Her generous sail plan delivers excellent light-air performance. Well-suited for coastal cruising with occasional overnight passages.
Construction Details
| Designer | Joubert-Nivelt |
|---|---|
| Length | 29.000 ft |
| LOA | 29.000 ft |
| LWL | 24.250 ft |
| Beam | 10.250 ft |
| Displacement | 6500 lb |
| Max Draft | 5.250 ft |
The standard boat dimensions
| i | 38.45 ft |
|---|---|
| j | 11.35 ft |
| p | 33.62 ft |
| e | 10.17 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 38.45 ft | 11.35 ft | 33.62 ft | 10.17 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 38.5 ft - (11735 mm) |
| Foot | 19 ft - (5791 mm) |
| Leech | 36.75 ft - (11201 mm) |
| Perc LP | * 165 |
| Area | * 549 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 38.09 ft - (11610 mm) |
| Foot | * 18.17 ft - (5538 mm) |
| Leech | * 36.03 ft - (10982 mm) |
| Percentage LP | * 150.04 % |
| Length Perpendicular | * 17.03 ft - (5191 mm) |
| Deck Angle | * 3.97 ° |
| Area | * 324.31 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 32.07 ft - (9775 mm) |
| Foot | * 14.84 ft - (4523 mm) |
| Leech | * 28.2 ft - (8595 mm) |
| Percentage LP | * 114.98 % |
| Length Perpendicular | * 13.05 ft - (3978 mm) |
| Deck Angle | * 12.01 ° |
| Area | * 209.22 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 33.62 ft - (10247 mm) |
| Foot | * 10.17 ft - (3100 mm) |
| Leech-AftHdBd | * 34.58 ft - (10540 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 34.78 ft - (10601 mm) |
| Head (inches) | * 4.5 in |
| Area (no Roach) | * 176.35 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 38.09 |
| MidGirth | * 20.43 ft - (6227 mm) |
| Foot | * 20.43 ft - (6227 mm) |
| Perc LP | * 180 |
| Area | * 661 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
