Tanzer 25
Description
The TANZER 25 is a compact cruiser designed by Joubert Nivelt. She strikes a balance between performance and comfort, Her generous sail plan delivers excellent light-air performance. Well-suited for coastal cruising with occasional overnight passages.
Construction Details
| Designer | Joubert Nivelt |
|---|---|
| Length | 25.000 ft |
| LOA | 25.250 ft |
| LWL | 21.830 ft |
| Beam | 9.580 ft |
| Displacement | 4200 lb |
| Max Draft | 4.700 ft |
The standard boat dimensions
| i | 31.56 ft |
|---|---|
| j | 9.32 ft |
| p | 32.57 ft |
| e | 11 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 31.56 ft | 9.32 ft | 32.57 ft | 11 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GENOA |
|---|---|
| Luff | * 31.26 ft - (9528 mm) |
| Foot | * 14.92 ft - (4548 mm) |
| Leech | * 29.56 ft - (9010 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 13.98 ft - (4261 mm) |
| Deck Angle | * 4 ° |
| Area | * 218.49 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 30 ft - (9144 mm) |
| Foot | 14 ft - (4267 mm) |
| Leech | 28.25 ft - (8611 mm) |
| Percentage LP | * 140.45 % |
| Length Perpendicular | * 13.09 ft - (3990 mm) |
| Deck Angle | * 4.32 ° |
| Area | * 196.35 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 31.33 ft - (9549 mm) |
| Foot | 14.42 ft - (4395 mm) |
| Leech | 29.67 ft - (9043 mm) |
| Percentage LP | * 145.39 % |
| Length Perpendicular | * 13.55 ft - (4130 mm) |
| Deck Angle | * 3.56 ° |
| Area | * 212.25 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 26.33 ft - (8025 mm) |
| Foot | * 12.19 ft - (3716 mm) |
| Leech | * 23.16 ft - (7059 mm) |
| Percentage LP | * 115.02 % |
| Length Perpendicular | * 10.72 ft - (3267 mm) |
| Deck Angle | * 11.96 ° |
| Area | * 141.14 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 32.57 ft - (9927 mm) |
| Foot | * 11 ft - (3353 mm) |
| Leech-AftHdBd | * 33.77 ft - (10293 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 34.01 ft - (10366 mm) |
| Head (inches) | * 5.25 in |
| Area (no Roach) | * 185.22 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 31.26 |
| MidGirth | * 16.78 ft - (5115 mm) |
| Foot | * 16.78 ft - (5115 mm) |
| Perc LP | * 180 |
| Area | * 446 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
