STONE HORSE
Description
The STONE HORSE is a dinghy. This nimble dinghy is designed for responsive sailing and easy handling, Her generous sail plan delivers excellent light-air performance. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 23.000 ft |
| LOA | 10.170 ft |
| LWL | 18.330 ft |
| Beam | 3.170 ft |
| Displacement | 80 lb |
| Max Draft | 3.500 ft |
The standard boat dimensions
| i | 28.50 ft |
|---|---|
| j | 10.50 ft |
| p | 25.83 ft |
| e | 12.83 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 28.50 ft | 10.50 ft | 25.83 ft | 12.83 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 28.85 ft - (8793 mm) |
| Foot | * 17.32 ft - (5279 mm) |
| Leech | * 26.54 ft - (8089 mm) |
| Perc LP | * 165 |
| Area | * 375 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 27.5 ft - (8382 mm) |
| Foot | 15.75 ft - (4801 mm) |
| Leech | 25.25 ft - (7696 mm) |
| Percentage LP | * 135.9 % |
| Length Perpendicular | * 14.27 ft - (4349 mm) |
| Deck Angle | * 4.82 ° |
| Area | * 196.2 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 28.85 ft - (8793 mm) |
| Foot | * 17.27 ft - (5264 mm) |
| Leech | * 26.87 ft - (8190 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 15.75 ft - (4801 mm) |
| Deck Angle | * 3.98 ° |
| Area | * 227.22 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 25.83 ft - (7873 mm) |
| Foot | * 12.83 ft - (3911 mm) |
| Leech-AftHdBd | * 28.15 ft - (8580 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 28.44 ft - (8669 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 171.36 ft² |
| Sail Type | YANKEE |
|---|---|
| Luff | 26.5 ft - (8077 mm) |
| Foot | 16 ft - (4877 mm) |
| Leech | 20.5 ft - (6248 mm) |
| Percentage LP | * 117.81 % |
| Length Perpendicular | * 12.37 ft - (3770 mm) |
| Deck Angle | * 19.15 ° |
| Area | * 163.87 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
