Sovereign 5.0
Description
The Sovereign 5.0 is a dinghy. This pocket cruiser packs surprising capability into a small package, Her generous sail plan delivers excellent light-air performance. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 17.000 ft |
| LOA | 17.000 ft |
| LWL | 14.500 ft |
| Beam | 7.000 ft |
| Displacement | 1350 lb |
| Max Draft | 1.830 ft |
The standard boat dimensions
| i | 18.16 ft |
|---|---|
| j | 6.16 ft |
| p | 17.33 ft |
| e | 7.75 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 18.16 ft | 6.16 ft | 17.33 ft | 7.75 ft | - | - |
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 17.33 ft - (5282 mm) |
| Foot | * 7.75 ft - (2362 mm) |
| Leech | * 18.57 ft - (5660 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 18.74 ft - (5712 mm) |
| Head (inches) | * 3.5 in - (89 mm) |
| Area | * 69.32 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 15.34 ft - (4676 mm) |
| Foot | * 8.24 ft - (2512 mm) |
| Leech | * 13.19 ft - (4020 mm) |
| Percentage LP | * 114.94 % |
| Length Perpendicular | * 7.08 ft - (2158 mm) |
| Deck Angle | * 12.01 ° |
| Area | * 54.32 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 18.22 ft - (5553 mm) |
| Foot | * 10.02 ft - (3054 mm) |
| Leech | * 17.06 ft - (5200 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 9.24 ft - (2816 mm) |
| Deck Angle | * 4.03 ° |
| Area | * 84.17 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 19 ft - (5791 mm) |
| Foot | 11.25 ft - (3429 mm) |
| Leech | 16.75 ft - (5105 mm) |
| Perc LP | * 165 % |
| Area | * 160 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
