SOVEREIGN 23 MK II
Description
The SOVEREIGN 23 MK II is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 23.000 ft |
The standard boat dimensions
| i | 29 ft |
|---|---|
| j | 10.20 ft |
| p | 24 ft |
| e | 8 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 29 ft | 10.20 ft | 24 ft | 8 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 24 ft - (7315 mm) |
| Foot | * 8 ft - (2438 mm) |
| Leech-AftHdBd | * 24.94 ft - (7602 mm) |
| Tack Ang | * 87.99 ° |
| Diag (clew/head) | * 25.03 ft - (7629 mm) |
| Head (inches) | * 3.5 in |
| Area (no Roach) | 95.89 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 29.2 ft - (8900 mm) |
| Foot | * 16.67 ft - (5081 mm) |
| Leech | * 27.28 ft - (8315 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 15.3 ft - (4663 mm) |
| Deck Angle | * 4 ° |
| Area | 223.4 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 24.59 ft - (7495 mm) |
| Foot | * 13.74 ft - (4188 mm) |
| Leech | * 21.01 ft - (6404 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 11.73 ft - (3575 mm) |
| Deck Angle | * 12 ° |
| Area | 144.2 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 29.2 ft - (8900 mm) |
| MidGirth | * 18.36 ft - (5596 mm) |
| Foot | * 18.36 ft - (5596 mm) |
| Perc LP | * 180 |
| Area | 455.7 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
