SHAMROCK CLUB RACER
Description
The SHAMROCK CLUB RACER is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 32.000 ft |
The standard boat dimensions
| i | 37 ft |
|---|---|
| j | 11.76 ft |
| p | 32 ft |
| e | 10 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 37 ft | 11.76 ft | 32 ft | 10 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 36.88 ft - (11241 mm) |
| MidGirth | * 21.17 ft - (6453 mm) |
| Foot | * 21.17 ft - (6453 mm) |
| Perc LP | * 180 |
| Area | 663.64 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 31.06 ft - (9467 mm) |
| Foot | * 15.56 ft - (4743 mm) |
| Leech | * 27 ft - (8230 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 13.52 ft - (4121 mm) |
| Deck Angle | * 12 ° |
| Area | 210.05 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 32 ft - (9754 mm) |
| Foot | * 10 ft - (3048 mm) |
| Leech-AftHdBd | * 33.08 ft - (10083 mm) |
| Tack Ang | * 87.99 ° |
| Diag (clew/head) | * 33.19 ft - (10116 mm) |
| Head (inches) | * 4.5 in |
| Area (no Roach) | 159.83 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 36.88 ft - (11241 mm) |
| Foot | * 18.98 ft - (5785 mm) |
| Leech | * 34.7 ft - (10577 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 17.64 ft - (5377 mm) |
| Deck Angle | * 4 ° |
| Area | 325.32 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
