SEAFARER 28
Description
The SEAFARER 28 is a performance cruiser. This substantial yacht offers spacious accommodations and excellent seakeeping, Her generous sail plan delivers excellent light-air performance. A true blue water cruiser capable of comfortable ocean passages.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 28.000 ft |
| LOA | 48.000 ft |
| LWL | 33.000 ft |
| Beam | 11.830 ft |
| Displacement | 30000 lb |
| Max Draft | 7.000 ft |
The standard boat dimensions
| i | 37.75 ft |
|---|---|
| j | 11.90 ft |
| p | 32 ft |
| e | 11 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 37.75 ft | 11.90 ft | 32 ft | 11 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 32 ft - (9754 mm) |
| Foot | * 11 ft - (3353 mm) |
| Leech-AftHdBd | * 33.33 ft - (10159 mm) |
| Tack Ang | * 87.98 ° |
| Diag (clew/head) | * 33.47 ft - (10202 mm) |
| Head (inches) | * 5.25 in |
| Area (no Roach) | 175.79 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 37.6 ft - (11460 mm) |
| Foot | * 19.18 ft - (5846 mm) |
| Leech | * 35.4 ft - (10790 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 17.85 ft - (5441 mm) |
| Deck Angle | * 4 ° |
| Area | 335.51 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 31.66 ft - (9650 mm) |
| Foot | * 15.72 ft - (4791 mm) |
| Leech | * 27.56 ft - (8400 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 13.69 ft - (4173 mm) |
| Deck Angle | * 12 ° |
| Area | 216.62 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 37.6 ft - (11460 mm) |
| MidGirth | * 21.42 ft - (6529 mm) |
| Foot | * 21.42 ft - (6529 mm) |
| Perc LP | * 180 |
| Area | 684.58 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
