Seacracker 33
Description
The Seacracker 33 is a mid-sized cruiser designed by E. G. Van de Stadt. Built for serious cruising, she offers reassuring stability in all conditions, Her generous sail plan delivers excellent light-air performance. A capable coastal cruiser with the ability to handle longer passages comfortably.
Construction Details
| Designer | E. G. Van de Stadt |
|---|---|
| Length | 33.000 ft |
| LOA | 32.830 ft |
| LWL | 24.000 ft |
| Beam | 9.180 ft |
| Displacement | 10430 lb |
| Max Draft | 4.670 ft |
The standard boat dimensions
| i | 37.73 ft |
|---|---|
| j | 11.55 ft |
| p | 31.17 ft |
| e | 10.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 37.73 ft | 11.55 ft | 31.17 ft | 10.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 31.17 ft - (9501 mm) |
| Foot | * 10.5 ft - (3200 mm) |
| Leech-AftHdBd | * 32.33 ft - (9854 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 32.54 ft - (9918 mm) |
| Head (inches) | * 4.5 in |
| Area (no Roach) | * 168.58 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 37.48 ft - (11424 mm) |
| Foot | * 18.55 ft - (5654 mm) |
| Leech | * 35.37 ft - (10781 mm) |
| Percentage LP | * 149.98 % |
| Length Perpendicular | * 17.32 ft - (5279 mm) |
| Deck Angle | * 3.96 ° |
| Area | * 324.59 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 36.5 ft - (11125 mm) |
| Foot | 18.5 ft - (5639 mm) |
| Leech | 34.5 ft - (10516 mm) |
| Percentage LP | * 149.55 % |
| Length Perpendicular | * 17.27 ft - (5264 mm) |
| Deck Angle | * 3.99 ° |
| Area | * 315.17 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | 19.5 ft - (5944 mm) |
| Foot | 9.75 ft - (2972 mm) |
| Leech | 15.75 ft - (4801 mm) |
| Perc LP | * 67.72 |
| Length Perp | * 7.82 |
| Deck Angle | * 19.68 ° |
| Area | * 76.22 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 38 ft - (11582 mm) |
| Foot | 20 ft - (6096 mm) |
| Leech | 35 ft - (10668 mm) |
| Perc LP | * 165 |
| Area | * 570 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
