Santana 228
Description
The SANTANA 228 is a compact cruiser designed by Shad Turner. Her substantial displacement provides a comfortable, sea-kindly motion, Her generous sail plan delivers excellent light-air performance. Well-suited for coastal cruising with occasional overnight passages.
Construction Details
| Designer | Shad Turner |
|---|---|
| Length | 28.000 ft |
| LOA | 28.290 ft |
| LWL | 23.000 ft |
| Beam | 9.200 ft |
| Displacement | 7500 lb |
| Max Draft | 5.000 ft |
The standard boat dimensions
| i | 38 ft |
|---|---|
| j | 12 ft |
| p | 33 ft |
| e | 10 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 38 ft | 12 ft | 33 ft | 10 ft | - | - | - | - |
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 33 ft - (10058 mm) |
| Foot | * 10 ft - (3048 mm) |
| Leech | * 33.95 ft - (10348 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 34.15 ft - (10409 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | * 170.3 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 31.88 ft - (9717 mm) |
| Foot | * 15.86 ft - (4834 mm) |
| Leech | * 27.74 ft - (8455 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 13.8 ft - (4206 mm) |
| Deck Angle | * 12 ° |
| Area | * 219.98 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 37.86 ft - (11540 mm) |
| Foot | * 19.35 ft - (5898 mm) |
| Leech | * 35.64 ft - (10863 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 18 ft - (5486 mm) |
| Deck Angle | * 4 ° |
| Area | * 340.75 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 37.86 ft - (11540 mm) |
| Foot | * 19.8 ft - (6035 mm) |
| Leech | * 34.83 ft - (10616 mm) |
| Perc LP | * 165 % |
| Area | * 562 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 37.86 ft - (11540 mm) |
| MidGirth | * 21.6 ft - (6584 mm) |
| Foot | * 21.6 ft - (6584 mm) |
| Perc LP | * 180 % |
| Area | * 695 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 21.92 ft - (6681 mm) |
| Foot | * 8.96 ft - (2731 mm) |
| Leech | * 18.08 ft - (5511 mm) |
| Perc LP | * 60 % |
| Length Perp | * 7.2 ft - (2195 mm) |
| Deck Angle | * 19.02 ° |
| Area | * 78.9 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
