SAN JUAN 33 S
Description
The SAN JUAN 33 S is a mid-sized cruiser. This performance-oriented design emphasizes speed and agility, Her generous sail plan delivers excellent light-air performance. A capable coastal cruiser with the ability to handle longer passages comfortably.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 33.000 ft |
| LOA | 33.100 ft |
| LWL | 27.800 ft |
| Beam | 7.950 ft |
| Displacement | 5700 lb |
| Max Draft | 5.500 ft |
The standard boat dimensions
| i | 35 ft |
|---|---|
| j | 11.50 ft |
| p | 40 ft |
| e | 13.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 35 ft | 11.50 ft | 40 ft | 13.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 40 ft - (12192 mm) |
| Foot | * 13.5 ft - (4115 mm) |
| Leech-AftHdBd | * 41.61 ft - (12683 mm) |
| Tack Ang | * 88.01 ° |
| Diag (clew/head) | * 41.77 ft - (12731 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 269.7 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 35 ft - (10668 mm) |
| Foot | * 18.63 ft - (5678 mm) |
| Leech | * 32.86 ft - (10016 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 17.25 ft - (5258 mm) |
| Deck Angle | * 4 ° |
| Area | 301.9 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 29.47 ft - (8982 mm) |
| Foot | * 15.3 ft - (4663 mm) |
| Leech | * 25.48 ft - (7766 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 13.23 ft - (4033 mm) |
| Deck Angle | * 12 ° |
| Area | 194.89 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 35 ft - (10668 mm) |
| MidGirth | * 20.7 ft - (6309 mm) |
| Foot | * 20.7 ft - (6309 mm) |
| Perc LP | * 180 |
| Area | 615.83 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
