SAILFISH 12
Description
The SAILFISH 12 is a compact cruiser. Her substantial displacement provides a comfortable, sea-kindly motion, featuring variable draft for versatility in different sailing conditions. Well-suited for coastal cruising with occasional overnight passages.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 12.000 ft |
| LOA | 25.420 ft |
| LWL | 20.000 ft |
| Beam | 9.330 ft |
| Displacement | 5000 lb |
| Max Draft | 5.000 ft |
| Min Draft | 1.160 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | 12.33 ft |
| e | 12.33 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | 12.33 ft | 12.33 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | LATEEN |
|---|---|
| Luff | 12.33 ft - (3758 mm) |
| Foot | 12.33 ft - (3758 mm) |
| Leech | 13.33 ft - (4063 mm) |
| Tack Ang | * 65.44 ° |
| Area | * 69.14 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
