SABRE 34 SERIES II HULL no.257-PRESENT
Description
The SABRE 34 SERIES II HULL no.257-PRESENT is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 34.000 ft |
The standard boat dimensions
| i | 44.71 ft |
|---|---|
| j | 13.75 ft |
| p | 39.14 ft |
| e | 11.92 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 44.71 ft | 13.75 ft | 39.14 ft | 11.92 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GENOA |
|---|---|
| Luff | 43 ft - (13106 mm) |
| Foot | 19.92 ft - (6072 mm) |
| Leech | 40.5 ft - (12344 mm) |
| Percentage LP | * 135.49 % |
| Length Perpendicular | * 18.63 ft - (5678 mm) |
| Deck Angle | * 3.61 ° |
| Area | * 400.63 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 39.14 ft - (11930 mm) |
| Foot | * 11.92 ft - (3633 mm) |
| Leech-AftHdBd | * 40.27 ft - (12274 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 40.51 ft - (12347 mm) |
| Head (inches) | * 5.25 in |
| Area (no Roach) | * 240.52 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 37.42 ft - (11406 mm) |
| Foot | * 18.09 ft - (5514 mm) |
| Leech | * 32.7 ft - (9967 mm) |
| Percentage LP | * 114.98 % |
| Length Perpendicular | * 15.81 ft - (4819 mm) |
| Deck Angle | * 12 ° |
| Area | * 295.77 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 44.44 ft - (13545 mm) |
| MidGirth | * 24.75 ft - (7544 mm) |
| Foot | * 24.75 ft - (7544 mm) |
| Perc LP | * 180 |
| Area | * 935 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 45 ft - (13716 mm) |
| Foot | 23 ft - (7010 mm) |
| Leech | 42 ft - (12802 mm) |
| Perc LP | * 165 |
| Area | * 776 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 25.73 ft - (7843 mm) |
| Foot | * 10.21 ft - (3112 mm) |
| Leech | * 21.37 ft - (6514 mm) |
| Perc LP | * 60 |
| Length Perp | * 8.25 |
| Deck Angle | * 19.01 ° |
| Area | * 106.12 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 44.44 ft - (13545 mm) |
| Foot | * 22.1 ft - (6736 mm) |
| Leech | * 41.91 ft - (12774 mm) |
| Percentage LP | * 149.96 % |
| Length Perpendicular | * 20.62 ft - (6285 mm) |
| Deck Angle | * 4 ° |
| Area | * 458.16 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
