RANGER 23 FUN
Description
The RANGER 23 FUN is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 23.000 ft |
The standard boat dimensions
| i | 24 ft |
|---|---|
| j | 8 ft |
| p | 27.89 ft |
| e | 10.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 24 ft | 8 ft | 27.89 ft | 10.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 24.03 ft - (7324 mm) |
| MidGirth | * 14.4 ft - (4389 mm) |
| Foot | * 14.4 ft - (4389 mm) |
| Perc LP | * 180 |
| Area | * 294 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 26 ft - (7925 mm) |
| Foot | 17 ft - (5182 mm) |
| Leech | 23 ft - (7010 mm) |
| Perc LP | * 165 |
| Area | * 332 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 24 ft - (7315 mm) |
| Foot | 12.083 ft - (3683 mm) |
| Leech | 22.5 ft - (6858 mm) |
| Percentage LP | * 140.25 % |
| Length Perpendicular | * 11.22 ft - (3420 mm) |
| Deck Angle | * 3.4 ° |
| Area | * 134.59 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 27.8 ft - (8473 mm) |
| Foot | 20.2 ft - (6157 mm) |
| Leech | 21.7 ft - (6614 mm) |
| Perc LP | * 165 |
| Area | * 421 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 24.25 ft - (7391 mm) |
| Foot | 13.083 ft - (3988 mm) |
| Leech | 22.5 ft - (6858 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 12 ft - (3658 mm) |
| Deck Angle | * 5.06 ° |
| Area | * 145.48 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 27.89 ft - (8501 mm) |
| Foot | * 10.5 ft - (3200 mm) |
| Leech-AftHdBd | * 29.25 ft - (8915 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 29.46 ft - (8979 mm) |
| Head (inches) | * 4.5 in |
| Area (no Roach) | * 150.9 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 24 ft - (7315 mm) |
| Foot | 9.42 ft - (2871 mm) |
| Leech | 21.5 ft - (6553 mm) |
| Percentage LP | * 105.25 % |
| Length Perpendicular | * 8.42 ft - (2566 mm) |
| Deck Angle | * 8.17 ° |
| Area | * 101.07 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 23.62 ft - (7199 mm) |
| Foot | 12.51 ft - (3813 mm) |
| Leech | 22.97 ft - (7001 mm) |
| Percentage LP | * 148.38 % |
| Length Perpendicular | * 11.87 ft - (3618 mm) |
| Deck Angle | * -0.01 ° |
| Area | * 140.17 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 25.26 ft - (7699 mm) |
| Foot | 12.98 ft - (3956 mm) |
| Leech | 23.622 ft - (7200 mm) |
| Percentage LP | * 150.12 % |
| Length Perpendicular | * 12.01 ft - (3661 mm) |
| Deck Angle | * 3.84 ° |
| Area | * 151.71 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
