Peep Hen
Description
630 lbs, 6'4" beam, 9" draft, Sail Area:115 Sq.Ft. Sailast:200lbs., LWL: 13'3"
Custom sail calculations are not possible for this boat as no I, J, P and E dimensions are available.
Construction Details
| Designer | Reuben Trane |
|---|---|
| Length | 14.000 ft |
| LOA | 14.170 ft |
| LWL | 13.250 ft |
| Beam | 6.330 ft |
| Displacement | 650 lb |
| Max Draft | 3.000 ft |
| Min Draft | 0.750 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | - | - | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GAFF MAIN |
|---|---|
| Luff | 11.167 ft - (3404 mm) |
| Foot | 10.75 ft - (3277 mm) |
| Leech | 19.167 ft - (5842 mm) |
| Tack Angle | * 81.09 ° |
| Diag (clew/throat) | 14.25 ft - (4343 mm) |
| Head | 8.83 ft - (2691 mm) |
| Area | * 118.39 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
