Pearson 34-2
Description
LWL 28.1 Beam 11.5 Disp 11500 Ballast 4500 Draft 4 Produced from 1989 to 1991
Construction Details
| Designer | Bill Shaw |
|---|---|
| Length | 34.500 ft |
| LOA | 34.500 ft |
| LWL | 28.170 ft |
| Beam | 11.500 ft |
| Displacement | 11800 lb |
| Max Draft | 4.000 ft |
The standard boat dimensions
| i | 44.25 ft |
|---|---|
| j | 13 ft |
| p | 38.33 ft |
| e | 13.70 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 44.25 ft | 13 ft | 38.33 ft | 13.70 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 38.33 ft - (11683 mm) |
| Foot | * 13.7 ft - (4176 mm) |
| Leech-AftHdBd | * 39.97 ft - (12183 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 40.25 ft - (12268 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 270.71 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 36.9 ft - (11247 mm) |
| Foot | * 16.99 ft - (5179 mm) |
| Leech | * 32.47 ft - (9897 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 14.95 ft - (4557 mm) |
| Deck Angle | * 12.01 ° |
| Area | * 275.79 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 42.75 ft - (13030 mm) |
| Foot | 15.58 ft - (4749 mm) |
| Leech | 39.25 ft - (11963 mm) |
| Percentage LP | * 110 % |
| Length Perpendicular | * 14.3 ft - (4359 mm) |
| Deck Angle | * 7.06 ° |
| Area | * 305.56 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 44.5 ft - (13564 mm) |
| Foot | 12.67 ft - (3862 mm) |
| Leech | 42.25 ft - (12878 mm) |
| Percentage LP | * 92.46 % |
| Length Perpendicular | * 12.02 ft - (3664 mm) |
| Deck Angle | * 2.02 ° |
| Area | * 267.51 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 43.5 ft - (13259 mm) |
| Foot | 18.67 ft - (5691 mm) |
| Leech | 41.25 ft - (12573 mm) |
| Percentage LP | * 135.46 % |
| Length Perpendicular | * 17.61 ft - (5368 mm) |
| Deck Angle | * 3.02 ° |
| Area | * 383.04 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 43.81 ft - (13353 mm) |
| Foot | * 20.8 ft - (6340 mm) |
| Leech | * 41.45 ft - (12634 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 19.5 ft - (5944 mm) |
| Deck Angle | * 3.98 ° |
| Area | * 427.18 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 44 ft - (13411 mm) |
| Foot | 22 ft - (6706 mm) |
| Leech | 41 ft - (12497 mm) |
| Perc LP | * 165 % |
| Area | * 726 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 43.81 ft - (13353 mm) |
| MidGirth | * 23.4 ft - (7132 mm) |
| Foot | * 23.4 ft - (7132 mm) |
| Perc LP | * 180 % |
| Area | * 871 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 25.37 ft - (7733 mm) |
| Foot | * 9.57 ft - (2917 mm) |
| Leech | * 21.3 ft - (6492 mm) |
| Perc LP | * 60 % |
| Length Perp | * 7.8 ft - (2377 mm) |
| Deck Angle | * 19.06 ° |
| Area | * 98.91 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
