PACESHIP 20
Description
The PACESHIP 20 is a dinghy designed by Cuthbertson and Cassian. This nimble dinghy is designed for responsive sailing and easy handling, making her ideal for exploring shallow waters and protected anchorages. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Construction Details
| Designer | Cuthbertson and Cassian |
|---|---|
| Length | 20.000 ft |
| LOA | 19.250 ft |
| LWL | 17.200 ft |
| Beam | 7.750 ft |
| Displacement | 800 lb |
| Max Draft | 3.000 ft |
| Min Draft | 0.580 ft |
The standard boat dimensions
| i | 17 ft |
|---|---|
| j | 7.66 ft |
| p | 20 ft |
| e | 9 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 17 ft | 7.66 ft | 20 ft | 9 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | JIBSAIL |
|---|---|
| Luff | 17.25 ft - (5258 mm) |
| Foot | 8.42 ft - (2566 mm) |
| Leech | 15.25 ft - (4648 mm) |
| Deck Angle | * 3.64 ° |
| Area | * 64.19 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | 17 ft - (5182 mm) |
| MidGirth | 12.17 ft - (3709 mm) |
| Foot | 13 ft - (3962 mm) |
| Perc LP | * 180 |
| Area | * 188 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 17.25 ft - (5258 mm) |
| Foot | 10.67 ft - (3252 mm) |
| Leech | 16.17 ft - (4929 mm) |
| Deck Angle | * -0.22 ° |
| Area | * 84.05 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | 20 ft - (6096 mm) |
| Foot | 9 ft - (2743 mm) |
| Leech-AftHdBd | * 21.5 ft - (6553 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 21.64 ft - (6596 mm) |
| Head (inches) | * 4 in |
| Area (no Roach) | * 93.2 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
