O'DAY 15
Description
The O'DAY 15 is a dinghy. This nimble dinghy is designed for responsive sailing and easy handling, making her ideal for exploring shallow waters and protected anchorages. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Sail calculations are not available for this boat as some dimensions are missing.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 15.000 ft |
| LOA | 13.670 ft |
| LWL | 12.500 ft |
| Beam | 6.170 ft |
| Displacement | 265 lb |
| Max Draft | 3.820 ft |
| Min Draft | 0.500 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | - | - | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | JIBSAIL |
|---|---|
| Luff | 15 ft - (4572 mm) |
| Foot | 6.5 ft - (1981 mm) |
| Leech | 14.25 ft - (4343 mm) |
| Length Perpendicular | 6.14 ft - (1871 mm) |
| Area | * 46.03 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | 19.5 ft - (5944 mm) |
| Foot | 8.75 ft - (2667 mm) |
| Leech-AftHdBd | * 20.9 ft - (6370 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 21.09 ft - (6428 mm) |
| Head (inches) | * 4 in |
| Area (no Roach) | * 88.13 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | 16 ft - (4877 mm) |
| MidGirth | 10.67 ft - (3252 mm) |
| Foot | 10.33 ft - (3149 mm) |
| Area | * 140 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
