OCEANIS 44 CENTER COCKPIT
Description
The OCEANIS 44 CENTER COCKPIT is a sailboat designed by Beneteau Yachts. Her generous sail plan delivers excellent light-air performance.
The standard boat dimensions
| i | 52.39 ft |
|---|---|
| j | 16.31 ft |
| p | 46.13 ft |
| e | 17.55 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 52.39 ft | 16.31 ft | 46.13 ft | 17.55 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 52.13 |
| MidGirth | * 29.36 ft - (8949 mm) |
| Foot | * 29.36 ft - (8949 mm) |
| Perc LP | * 180 |
| Area | * 1301 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 46.13 ft - (14060 mm) |
| Foot | * 17.55 ft - (5349 mm) |
| Leech-AftHdBd | * 48.43 ft - (14761 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 48.78 ft - (14868 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 413.22 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 43.9 ft - (13381 mm) |
| Foot | * 21.51 ft - (6556 mm) |
| Leech | * 38.29 ft - (11671 mm) |
| Percentage LP | * 115.02 % |
| Length Perpendicular | * 18.76 ft - (5718 mm) |
| Deck Angle | * 11.99 ° |
| Area | * 411.81 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 52.13 ft - (15889 mm) |
| Foot | * 26.25 ft - (8001 mm) |
| Leech | * 49.13 ft - (14975 mm) |
| Percentage LP | * 149.97 % |
| Length Perpendicular | * 24.46 ft - (7455 mm) |
| Deck Angle | * 3.98 ° |
| Area | * 637.6 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 52.13 ft - (15889 mm) |
| Foot | * 26.91 ft - (8202 mm) |
| Leech | * 47.96 ft - (14618 mm) |
| Perc LP | * 165 |
| Area | * 1052 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 30.18 ft - (9199 mm) |
| Foot | * 12.15 ft - (3703 mm) |
| Leech | * 24.98 ft - (7614 mm) |
| Perc LP | * 60.02 |
| Length Perp | * 9.79 |
| Deck Angle | * 19.04 ° |
| Area | * 147.71 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
