NORTHWIND 47
Description
The NORTHWIND 47 is a performance cruiser. This substantial yacht offers spacious accommodations and excellent seakeeping, Her generous sail plan delivers excellent light-air performance. A true blue water cruiser capable of comfortable ocean passages.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 47.000 ft |
| LOA | 46.750 ft |
| LWL | 37.340 ft |
| Beam | 13.880 ft |
| Displacement | 28660 lb |
| Max Draft | 6.560 ft |
The standard boat dimensions
| i | 55.81 ft |
|---|---|
| j | 17.72 ft |
| p | 49.25 ft |
| e | 14.76 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 55.81 ft | 17.72 ft | 49.25 ft | 14.76 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 46.84 ft - (14277 mm) |
| Foot | * 23.44 ft - (7145 mm) |
| Leech | * 40.72 ft - (12411 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 20.38 ft - (6212 mm) |
| Deck Angle | * 12 ° |
| Area | 477.23 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 49.25 ft - (15011 mm) |
| Foot | * 14.76 ft - (4499 mm) |
| Leech-AftHdBd | * 50.78 ft - (15478 mm) |
| Tack Ang | * 88.01 ° |
| Diag (clew/head) | * 50.92 ft - (15520 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 363.1 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 55.63 ft - (16956 mm) |
| Foot | * 28.59 ft - (8714 mm) |
| Leech | * 52.35 ft - (15956 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 26.58 ft - (8102 mm) |
| Deck Angle | * 4 ° |
| Area | 739.33 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 55.63 ft - (16956 mm) |
| MidGirth | * 31.9 ft - (9723 mm) |
| Foot | * 31.9 ft - (9723 mm) |
| Perc LP | * 180 |
| Area | 1508.41 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
