NAJADVARVET NAJAD 343
Description
The NAJADVARVET NAJAD 343 is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 34.000 ft |
The standard boat dimensions
| i | 40.85 ft |
|---|---|
| j | 11.81 ft |
| p | 36.42 ft |
| e | 14.27 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 40.85 ft | 11.81 ft | 36.42 ft | 14.27 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 36.42 ft - (11101 mm) |
| Foot | * 14.27 ft - (4349 mm) |
| Leech-AftHdBd | * 38.47 ft - (11726 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 38.65 ft - (11781 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 259.55 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 34.02 ft - (10369 mm) |
| Foot | * 15.4 ft - (4694 mm) |
| Leech | * 30.01 ft - (9147 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 13.58 ft - (4139 mm) |
| Deck Angle | * 12 ° |
| Area | 231.03 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 40.4 ft - (12314 mm) |
| Foot | * 18.87 ft - (5752 mm) |
| Leech | * 38.26 ft - (11662 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 17.72 ft - (5401 mm) |
| Deck Angle | * 4 ° |
| Area | 357.92 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 40.4 ft - (12314 mm) |
| MidGirth | * 21.26 ft - (6480 mm) |
| Foot | * 21.26 ft - (6480 mm) |
| Perc LP | * 180 |
| Area | 730.07 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
