Morgan Oi 33
Description
14500 lbs. Disp. 5000 lbs. Ballast 27'6" LWL 11'10" Beam 3'11" Draft
The standard boat dimensions
| i | 40.50 ft |
|---|---|
| j | 13.50 ft |
| p | 35.50 ft |
| e | 14 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 40.50 ft | 13.50 ft | 35.50 ft | 14 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 35.5 ft - (10820 mm) |
| Foot | * 14 ft - (4267 mm) |
| Leech | * 37.42 ft - (11406 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 37.7 ft - (11491 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 256.13 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 34.15 ft - (10409 mm) |
| Foot | * 18 ft - (5486 mm) |
| Leech | * 29.45 ft - (8976 mm) |
| Percentage LP | * 114.96 % |
| Length Perpendicular | * 15.52 ft - (4730 mm) |
| Deck Angle | * 12.01 ° |
| Area | * 264.98 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 35 ft - (10668 mm) |
| Foot | 15.75 ft - (4801 mm) |
| Leech | 30 ft - (9144 mm) |
| Percentage LP | * 99.7 % |
| Length Perpendicular | * 13.46 ft - (4103 mm) |
| Deck Angle | * 12.88 ° |
| Area | * 235.47 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 40.56 ft - (12363 mm) |
| Foot | * 21.91 ft - (6678 mm) |
| Leech | * 38.03 ft - (11592 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 20.25 ft - (6172 mm) |
| Deck Angle | * 4.02 ° |
| Area | * 410.64 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 39.5 ft - (12040 mm) |
| Foot | 19.92 ft - (6072 mm) |
| Leech | 36.5 ft - (11125 mm) |
| Percentage LP | * 135.41 % |
| Length Perpendicular | * 18.28 ft - (5572 mm) |
| Deck Angle | * 4.96 ° |
| Area | * 361.08 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 40.56 ft - (12363 mm) |
| Foot | * 15.85 ft - (4831 mm) |
| Leech | * 38.04 ft - (11595 mm) |
| Percentage LP | 110 % |
| Length Perpendicular | * 14.85 ft - (4526 mm) |
| Deck Angle | * 2.02 ° |
| Area | * 301.17 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 39.25 ft - (11963 mm) |
| Foot | 18.92 ft - (5767 mm) |
| Leech | 36 ft - (10973 mm) |
| Percentage LP | * 128.07 % |
| Length Perpendicular | * 17.29 ft - (5270 mm) |
| Deck Angle | * 5.5 ° |
| Area | * 339.38 ft² |
| Sail Type | DRIFTER |
|---|---|
| Luff | 40.5 ft - (12344 mm) |
| Foot | 22.83 ft - (6959 mm) |
| Leech | 36.5 ft - (11125 mm) |
| Perc LP | * 151.19 % |
| Length Perp | * 20.41 ft - (6221 mm) |
| Deck Angle | * 8.21 ° |
| Area | * 413.22 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 40.56 ft - (12363 mm) |
| Foot | * 22.28 ft - (6791 mm) |
| Leech | * 37.32 ft - (11375 mm) |
| Perc LP | * 165 % |
| Area | * 678 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 23.48 ft - (7157 mm) |
| Foot | * 10.2 ft - (3109 mm) |
| Leech | * 19.08 ft - (5816 mm) |
| Perc LP | * 60 % |
| Length Perp | * 8.1 ft - (2469 mm) |
| Deck Angle | * 19.02 ° |
| Area | * 95.06 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
