Morgan 36t
Description
The Morgan 36T is a cruising yacht designed by Charley Morgan. She combines good sailing performance with comfortable accommodations, Her generous sail plan delivers excellent light-air performance. Designed for serious cruising, whether coastal hopping or ocean crossings.
Construction Details
| Designer | Charley Morgan |
|---|---|
| Length | 35.750 ft |
| LOA | 35.750 ft |
| LWL | 30.000 ft |
| Beam | 11.750 ft |
| Displacement | 14000 lb |
| Max Draft | 6.250 ft |
The standard boat dimensions
| i | 48 ft |
|---|---|
| j | 15 ft |
| p | 42.50 ft |
| e | 12.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 48 ft | 15 ft | 42.50 ft | 12.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 42.5 ft - (12954 mm) |
| Foot | * 12.5 ft - (3810 mm) |
| Leech | * 43.61 ft - (13292 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 43.88 ft - (13375 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 274.66 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 40.23 ft - (12262 mm) |
| Foot | * 19.79 ft - (6032 mm) |
| Leech | * 35.07 ft - (10689 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 17.25 ft - (5258 mm) |
| Deck Angle | * 11.99 ° |
| Area | * 347.02 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 47.77 ft - (14560 mm) |
| Foot | * 24.16 ft - (7364 mm) |
| Leech | * 45 ft - (13716 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 22.5 ft - (6858 mm) |
| Deck Angle | * 4 ° |
| Area | * 537.43 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 47.77 ft - (14560 mm) |
| Foot | * 24.75 ft - (7544 mm) |
| Leech | * 43.95 ft - (13396 mm) |
| Perc LP | * 165 % |
| Area | * 887 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 49 ft - (14935 mm) |
| Foot | 27 ft - (8230 mm) |
| Leech | 45.5 ft - (13868 mm) |
| Perc LP | * 165 % |
| Area | * 992 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 47.77 ft - (14560 mm) |
| MidGirth | * 27 ft - (8230 mm) |
| Foot | * 27 ft - (8230 mm) |
| Perc LP | * 180 % |
| Area | * 1096 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
