Mirage 28
Description
Introduced in 1980.
The standard boat dimensions
| i | 35 ft |
|---|---|
| j | 11.25 ft |
| p | 29 ft |
| e | 10 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 35 ft | 11.25 ft | 29 ft | 10 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 29 ft - (8839 mm) |
| Foot | * 10 ft - (3048 mm) |
| Leech | * 30.13 ft - (9184 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 30.34 ft - (9248 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | * 149.61 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 29.41 ft - (8964 mm) |
| Foot | * 14.91 ft - (4545 mm) |
| Leech | * 25.53 ft - (7782 mm) |
| Percentage LP | * 115.02 % |
| Length Perpendicular | * 12.94 ft - (3944 mm) |
| Deck Angle | * 11.95 ° |
| Area | * 190.31 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 33.75 ft - (10287 mm) |
| Foot | 15.75 ft - (4801 mm) |
| Leech | 31.75 ft - (9677 mm) |
| Percentage LP | * 130.76 % |
| Length Perpendicular | * 14.71 ft - (4484 mm) |
| Deck Angle | * 3.07 ° |
| Area | * 248.31 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 34.93 ft - (10647 mm) |
| Foot | * 18.18 ft - (5541 mm) |
| Leech | * 32.85 ft - (10013 mm) |
| Percentage LP | * 150.04 % |
| Length Perpendicular | * 16.88 ft - (5145 mm) |
| Deck Angle | * 3.97 ° |
| Area | * 294.82 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 34.5 ft - (10516 mm) |
| Foot | 18.5 ft - (5639 mm) |
| Leech | 31 ft - (9449 mm) |
| Perc LP | * 165 % |
| Area | * 479 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 34.93 ft - (10647 mm) |
| MidGirth | * 20.25 ft - (6172 mm) |
| Foot | * 20.25 ft - (6172 mm) |
| Perc LP | * 180 % |
| Area | * 601 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
