MELONSEED SKIFF 13'
Description
The MELONSEED SKIFF 13' is a sailboat.
Sail calculations are not available for this boat as some dimensions are missing.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 13.540 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | - | - | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | SPRIT |
|---|---|
| Luff | 7.25 ft - (2210 mm) |
| Foot | 9 ft - (2743 mm) |
| Leech | 11 ft - (3353 mm) |
| Head | * 84.48 ft - (25750 mm) |
| Diag (clew/throat) | 11 ft - (3353 mm) |
| Tack Angle | 5.33 ° |
| Area | * 60.91 ft² |
| Sail Type | SPRIT |
|---|---|
| Luff | 7.25 ft - (2210 mm) |
| Foot | 9 ft - (2743 mm) |
| Leech | 13.125 ft - (4001 mm) |
| Head | * 79.71 ft - (24296 mm) |
| Diag (clew/throat) | 10.5 ft - (3200 mm) |
| Tack Angle | 6.5 ° |
| Area | * 65.87 ft² |
| Sail Type | SPRIT |
|---|---|
| Luff | 7.167 ft - (2185 mm) |
| Foot | 8.83 ft - (2691 mm) |
| Leech | 10.167 ft - (3099 mm) |
| Head | * 77.37 ft - (23582 mm) |
| Diag (clew/throat) | 10.083 ft - (3073 mm) |
| Tack Angle | 4.5 ° |
| Area | * 53.09 ft² |
| Sail Type | SPRIT |
|---|---|
| Luff | 8.083 ft - (2464 mm) |
| Foot | 9 ft - (2743 mm) |
| Leech | 10.83 ft - (3301 mm) |
| Head | * 84.44 ft - (25737 mm) |
| Diag (clew/throat) | 11.5 ft - (3505 mm) |
| Tack Angle | 4.67 ° |
| Area | * 61.43 ft² |
| Sail Type | LUGSAIL |
|---|---|
| Luff | 6 ft - (1829 mm) |
| Foot | 9 ft - (2743 mm) |
| Leech | 11.75 ft - (3581 mm) |
| Head | * 86.42 ft - (26341 mm) |
| Diag (clew/throat) | 10.5 ft - (3200 mm) |
| Tack Angle | 6 ° |
| Area | * 58.38 ft² |
| Sail Type | SPRIT |
|---|---|
| Luff | 8.167 ft - (2489 mm) |
| Foot | 9.58 ft - (2920 mm) |
| Leech | 11.5 ft - (3505 mm) |
| Head | * 78.91 ft - (24052 mm) |
| Diag (clew/throat) | 11.33 ft - (3453 mm) |
| Tack Angle | 5.33 ° |
| Area | * 67.96 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
