Malo 116
Description
The MALO 116 is a mid-sized cruiser designed by Olsöners Båtbyggen. Built for serious cruising, she offers reassuring stability in all conditions, Her generous sail plan delivers excellent light-air performance. A capable coastal cruiser with the ability to handle longer passages comfortably.
Construction Details
| Designer | Olsöners Båtbyggen |
|---|---|
| Length | 38.000 ft |
| LOA | 34.780 ft |
| LWL | 28.220 ft |
| Beam | 10.730 ft |
| Displacement | 14550 lb |
| Max Draft | 5.250 ft |
The standard boat dimensions
| i | 51.51 ft |
|---|---|
| j | 15.42 ft |
| p | 45.60 ft |
| e | 13.94 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 51.51 ft | 15.42 ft | 45.60 ft | 13.94 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 45.6 ft - (13899 mm) |
| Foot | * 13.94 ft - (4249 mm) |
| Leech | * 47.07 ft - (14347 mm) |
| Tack Angle | * 88.02 ° |
| Diagonal | * 47.22 ft - (14393 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 317.5 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 43.01 ft - (13109 mm) |
| Foot | * 20.21 ft - (6160 mm) |
| Leech | * 37.74 ft - (11503 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 17.73 ft - (5404 mm) |
| Deck Angle | * 12 ° |
| Area | 381.34 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 51.08 ft - (15569 mm) |
| Foot | * 24.72 ft - (7535 mm) |
| Leech | * 48.26 ft - (14710 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 23.13 ft - (7050 mm) |
| Deck Angle | * 4 ° |
| Area | 590.73 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 51.08 ft - (15569 mm) |
| MidGirth | * 27.76 ft - (8461 mm) |
| Foot | * 27.76 ft - (8461 mm) |
| Perc LP | * 180 % |
| Area | 1205.28 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
