LANCER 25
Description
3400 lbs. Disp. 1200 lbs. Ballast 20'1" LWL 8' Beam 2'10" Draft
Construction Details
| Designer | W. Shad Turner |
|---|---|
| Length | 24.670 ft |
| LOA | 24.670 ft |
| LWL | 20.080 ft |
| Beam | 8.000 ft |
| Displacement | 3400 lb |
| Max Draft | 2.330 ft |
The standard boat dimensions
| i | 28.50 ft |
|---|---|
| j | 10.25 ft |
| p | 24 ft |
| e | 8.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 28.50 ft | 10.25 ft | 24 ft | 8.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 24 ft - (7315 mm) |
| Foot | * 8.5 ft - (2591 mm) |
| Leech-AftHdBd | * 25 ft - (7620 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 25.18 ft - (7675 mm) |
| Head (inches) | * 4 in |
| Area (no Roach) | * 105.46 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 28.77 ft - (8769 mm) |
| Foot | * 16.94 ft - (5163 mm) |
| Leech | * 25.49 ft - (7769 mm) |
| Percentage LP | * 145.27 % |
| Length Perpendicular | * 14.89 ft - (4538 mm) |
| Deck Angle | * 8.71 ° |
| Area | * 214.17 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 24.23 ft - (7385 mm) |
| Foot | * 14.03 ft - (4276 mm) |
| Leech | * 19.48 ft - (5938 mm) |
| Percentage LP | * 110.05 % |
| Length Perpendicular | * 11.28 ft - (3438 mm) |
| Deck Angle | * 16.72 ° |
| Area | * 136.63 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 28.77 ft - (8769 mm) |
| MidGirth | * 18.45 ft - (5624 mm) |
| Foot | * 18.45 ft - (5624 mm) |
| Perc LP | * 180 |
| Area | * 451 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 29 ft - (8839 mm) |
| Foot | 17 ft - (5182 mm) |
| Leech | 27 ft - (8230 mm) |
| Perc LP | * 165 |
| Area | * 370 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 27.5 ft - (8382 mm) |
| Foot | 13.5 ft - (4115 mm) |
| Leech | 25 ft - (7620 mm) |
| Percentage LP | * 119.41 % |
| Length Perpendicular | * 12.24 ft - (3731 mm) |
| Deck Angle | * 5.19 ° |
| Area | * 168.27 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 27.5 ft - (8382 mm) |
| Foot | 16.83 ft - (5130 mm) |
| Leech | 25.75 ft - (7849 mm) |
| Percentage LP | * 150.05 % |
| Length Perpendicular | * 15.38 ft - (4688 mm) |
| Deck Angle | * 4.21 ° |
| Area | * 211.41 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
