Kelly Peterson 44 ketch
Description
The Kelly Peterson 44 ketch is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 44.000 ft |
The standard boat dimensions
| i | 50.92 ft |
|---|---|
| j | 17.58 ft |
| p | 45.33 ft |
| e | 14.60 ft |
| p2 | 34.58 ft |
| e2 | 11.58 ft |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 50.92 ft | 17.58 ft | 45.33 ft | 14.60 ft | 34.58 ft | 11.58 ft |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 45.33 ft - (13817 mm) |
| Foot | * 14.6 ft - (4450 mm) |
| Leech-AftHdBd | * 46.87 ft - (14286 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 47.14 ft - (14368 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 340.6 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 50 ft - (15240 mm) |
| Foot | 25 ft - (7620 mm) |
| Leech | 46 ft - (14021 mm) |
| Percentage LP | * 130.09 % |
| Length Perpendicular | * 22.87 ft - (6971 mm) |
| Deck Angle | * 4.76 ° |
| Area | * 571.83 ft² |
| Sail Type | STAYSAIL |
|---|---|
| Luff | 31 ft - (9449 mm) |
| Foot | 12.25 ft - (3734 mm) |
| Leech | 26.75 ft - (8153 mm) |
| Length Perpendicular | * 10.46 ft - (3188 mm) |
| Area | * 162.1 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | 25 ft - (7620 mm) |
| Foot | 12 ft - (3658 mm) |
| Leech | 20 ft - (6096 mm) |
| Length Perp | * 9.46 |
| Area | * 118.28 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 55 ft - (16764 mm) |
| Foot | 31.5 ft - (9601 mm) |
| Leech | 52 ft - (15850 mm) |
| Perc LP | * 165 |
| Area | * 1299 ft² |
| Sail Type | STORMTRYSAIL |
|---|---|
| Luff | 17 ft - (5182 mm) |
| Foot | 15.5 ft - (4724 mm) |
| Leech | * 13.87 ft - (4228 mm) |
| Length Perp | * 13.87 |
| Tack Angle | * -25 ° |
| Area | * 101 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 50 ft - (15240 mm) |
| Foot | 26 ft - (7925 mm) |
| Leech | 46 ft - (14021 mm) |
| Percentage LP | * 135.04 % |
| Length Perpendicular | * 23.74 ft - (7236 mm) |
| Deck Angle | * 5.01 ° |
| Area | * 593.53 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
