Irwin 41 Sloop
Description
The Irwin 31 Sloop is a fiberglass masthead sloop designed by Ted Irwin and built by Irwin Yachts in St. Petersburg, Florida, from 1967 to approximately 1975. As one of the first models produced by Irwin Yachts after its founding in 1966, the Irwin 31 was designed as an affordable coastal cruiser for families and novice sailors, emphasizing simplicity, a roomy interior for its size, and ease of handling. It predates the later Citation series (e.g., Citation 31) and lacks the performance-oriented features of those models, focusing instead on comfort for weekend sailing or short coastal trips in protected waters like bays, lakes, or nearshore routes (e.g., Florida to Bahamas). Approximately 200-300 hulls were built, making it a relatively rare classic today. It was offered with a fixed fin keel or an optional keel/centerboard for shallow-water versatility.
The standard boat dimensions
| i | 55.18 ft |
|---|---|
| j | 16.86 ft |
| p | 47.49 ft |
| e | 13.50 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 55.18 ft | 16.86 ft | 47.49 ft | 13.50 ft | - | - | - | - |
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 47.49 ft - (14475 mm) |
| Foot | * 13.5 ft - (4115 mm) |
| Leech | * 48.78 ft - (14868 mm) |
| Tack Angle | * 88.02 ° |
| Diagonal | * 48.92 ft - (14911 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 320.23 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 46.16 ft - (14070 mm) |
| Foot | * 22.17 ft - (6757 mm) |
| Leech | * 40.38 ft - (12308 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 19.39 ft - (5910 mm) |
| Deck Angle | * 12 ° |
| Area | 447.61 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 54.81 ft - (16706 mm) |
| Foot | * 27.09 ft - (8257 mm) |
| Leech | * 51.71 ft - (15761 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 25.29 ft - (7708 mm) |
| Deck Angle | * 4 ° |
| Area | 693.1 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 54.81 ft - (16706 mm) |
| MidGirth | * 30.35 ft - (9251 mm) |
| Foot | * 30.35 ft - (9251 mm) |
| Perc LP | * 180 % |
| Area | 1413.96 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
