HUNTER SONATA 22
Description
The HUNTER SONATA 22 is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 23.000 ft |
The standard boat dimensions
| i | 24.85 ft |
|---|---|
| j | 8 ft |
| p | 26 ft |
| e | 8.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 24.85 ft | 8 ft | 26 ft | 8.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 24.8 ft - (7559 mm) |
| MidGirth | * 14.4 ft - (4389 mm) |
| Foot | * 14.4 ft - (4389 mm) |
| Perc LP | * 180 |
| Area | 303.55 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 26 ft - (7925 mm) |
| Foot | * 8.5 ft - (2591 mm) |
| Leech-AftHdBd | * 26.97 ft - (8220 mm) |
| Tack Ang | * 87.99 ° |
| Diag (clew/head) | * 27.07 ft - (8251 mm) |
| Head (inches) | * 4 in |
| Area (no Roach) | 110.38 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 24.8 ft - (7559 mm) |
| Foot | * 12.93 ft - (3941 mm) |
| Leech | * 23.31 ft - (7105 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 12 ft - (3658 mm) |
| Deck Angle | * 4 ° |
| Area | 148.8 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 20.88 ft - (6364 mm) |
| Foot | * 10.61 ft - (3234 mm) |
| Leech | * 18.11 ft - (5520 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 9.2 ft - (2804 mm) |
| Deck Angle | * 12 ° |
| Area | 96.07 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
