Hunter 50 AC
Description
The Hunter 50 AC is a performance cruiser. This substantial yacht offers spacious accommodations and excellent seakeeping, Her generous sail plan delivers excellent light-air performance. A true blue water cruiser capable of comfortable ocean passages.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 49.920 ft |
| LOA | 40.320 ft |
| LWL | 35.500 ft |
| Beam | 13.250 ft |
| Displacement | 19400 lb |
| Max Draft | 6.500 ft |
The standard boat dimensions
| i | 54.58 ft |
|---|---|
| j | 16.50 ft |
| p | 51.58 ft |
| e | 21.83 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 54.58 ft | 16.50 ft | 51.58 ft | 21.83 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 51.58 ft - (15722 mm) |
| Foot | * 21.83 ft - (6654 mm) |
| Leech-AftHdBd | * 55.02 ft - (16770 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 55.3 ft - (16855 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 574.07 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 45.62 ft - (13905 mm) |
| Foot | * 21.66 ft - (6602 mm) |
| Leech | * 39.98 ft - (12186 mm) |
| Percentage LP | * 115.03 % |
| Length Perpendicular | * 18.98 ft - (5785 mm) |
| Deck Angle | * 11.98 ° |
| Area | * 432.97 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 54.17 ft - (16511 mm) |
| Foot | * 26.48 ft - (8071 mm) |
| Leech | * 51.14 ft - (15587 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 24.75 ft - (7544 mm) |
| Deck Angle | * 4.01 ° |
| Area | * 670.32 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 57 ft - (17374 mm) |
| Foot | 29 ft - (8839 mm) |
| Leech | 53 ft - (16154 mm) |
| Perc LP | * 165 |
| Area | * 1240 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
