HINCKLEY SOU'WESTER 51
Description
The HINCKLEY SOU'WESTER 51 is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 51.000 ft |
The standard boat dimensions
| i | 61.52 ft |
|---|---|
| j | 20.21 ft |
| p | 53.41 ft |
| e | 19 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 61.52 ft | 20.21 ft | 53.41 ft | 19 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 53.41 ft - (16279 mm) |
| Foot | * 19 ft - (5791 mm) |
| Leech-AftHdBd | * 55.89 ft - (17035 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 56.06 ft - (17087 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 506.9 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 51.8 ft - (15789 mm) |
| Foot | * 26.89 ft - (8196 mm) |
| Leech | * 44.78 ft - (13649 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 23.24 ft - (7084 mm) |
| Deck Angle | * 12 ° |
| Area | 601.96 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 61.52 ft - (18751 mm) |
| Foot | * 32.74 ft - (9979 mm) |
| Leech | * 57.75 ft - (17602 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 30.32 ft - (9242 mm) |
| Deck Angle | * 4 ° |
| Area | 932.48 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 61.52 ft - (18751 mm) |
| MidGirth | * 36.38 ft - (11089 mm) |
| Foot | * 36.38 ft - (11089 mm) |
| Perc LP | * 180 |
| Area | 1902.38 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
