HINCKLEY PILOT 35
Description
The HINCKLEY PILOT 35 is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 35.000 ft |
The standard boat dimensions
| i | 40.30 ft |
|---|---|
| j | 13.80 ft |
| p | 35.10 ft |
| e | 15.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 40.30 ft | 13.80 ft | 35.10 ft | 15.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GENOA |
|---|---|
| Luff | 39 ft - (11887 mm) |
| Foot | 19.5 ft - (5944 mm) |
| Leech | 36 ft - (10973 mm) |
| Percentage LP | * 129.64 % |
| Length Perpendicular | * 17.89 ft - (5453 mm) |
| Deck Angle | * 4.55 ° |
| Area | * 348.85 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 40.47 ft - (12335 mm) |
| Foot | * 22.77 ft - (6940 mm) |
| Leech | * 37.23 ft - (11348 mm) |
| Perc LP | * 165 |
| Area | * 691 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 23.43 ft - (7141 mm) |
| Foot | * 10.54 ft - (3213 mm) |
| Leech | * 18.09 ft - (5514 mm) |
| Perc LP | * 56.45 |
| Length Perp | * 7.79 |
| Deck Angle | * 23.46 ° |
| Area | * 91.23 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 40.47 ft - (12335 mm) |
| Foot | * 22.48 ft - (6852 mm) |
| Leech | * 36.56 ft - (11143 mm) |
| Percentage LP | * 146.01 % |
| Length Perpendicular | * 20.15 ft - (6142 mm) |
| Deck Angle | * 7.41 ° |
| Area | * 407.75 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 34.08 ft - (10388 mm) |
| Foot | * 18.55 ft - (5654 mm) |
| Leech | * 28.14 ft - (8577 mm) |
| Percentage LP | * 110.94 % |
| Length Perpendicular | * 15.31 ft - (4666 mm) |
| Deck Angle | * 15.46 ° |
| Area | * 260.92 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 35.1 ft - (10698 mm) |
| Foot | * 15.5 ft - (4724 mm) |
| Leech-AftHdBd | * 37.59 ft - (11457 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 37.87 ft - (11543 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 279.67 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
