Hinckley Bermuda 40 MK III
Description
The Hinckley Bermuda 40 MK III is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 40.000 ft |
The standard boat dimensions
| i | 48.90 ft |
|---|---|
| j | 17.40 ft |
| p | 42.30 ft |
| e | 12 ft |
| p2 | 29.50 ft |
| e2 | 10.50 ft |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 48.90 ft | 17.40 ft | 42.30 ft | 12 ft | 29.50 ft | 10.50 ft |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 42.3 ft - (12893 mm) |
| Foot | * 12 ft - (3658 mm) |
| Leech-AftHdBd | * 43.32 ft - (13204 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 43.56 ft - (13277 mm) |
| Head (inches) | * 5.25 in |
| Area (no Roach) | * 261.58 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 41.52 ft - (12655 mm) |
| Foot | * 23.49 ft - (7160 mm) |
| Leech | * 35.41 ft - (10793 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 20.01 ft - (6099 mm) |
| Deck Angle | * 12 ° |
| Area | * 415.39 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 49.31 ft - (15030 mm) |
| Foot | * 28.48 ft - (8681 mm) |
| Leech | * 46.03 ft - (14030 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 26.1 ft - (7955 mm) |
| Deck Angle | * 4 ° |
| Area | * 643.52 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 50 ft - (15240 mm) |
| Foot | 30 ft - (9144 mm) |
| Leech | 47 ft - (14326 mm) |
| Perc LP | * 165 |
| Area | * 1125 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 28.55 ft - (8702 mm) |
| Foot | * 13.36 ft - (4072 mm) |
| Leech | * 22.75 ft - (6934 mm) |
| Perc LP | * 60 |
| Length Perp | * 10.44 |
| Deck Angle | * 19.02 ° |
| Area | * 149.03 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
