Herreshoff America
Description
"2500 Lbs" Catboat, Hull same as Herreshoff Eagle. Single Gaff rig 250 sq ft with flag emblem.
Sail calculations are not available for this boat as some dimensions are missing.
Construction Details
| Designer | H. Herreshoff |
|---|---|
| Length | 18.000 ft |
| LOA | 18.160 ft |
| LWL | 17.750 ft |
| Beam | 8.000 ft |
| Displacement | 2500 lb |
| Min Draft | 1.830 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | - | - | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GAFF MAIN |
|---|---|
| Luff | 13.42 ft - (4090 mm) |
| Foot | 17.67 ft - (5386 mm) |
| Leech | 29.83 ft - (9092 mm) |
| Head | * 87.25 ft - (26594 mm) |
| Diag (clew/throat) | 21.67 ft - (6605 mm) |
| Tack Angle | 14.42 ° |
| Area | 250 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
