FANTASIA 34
Description
The FANTASIA 34 is a cruising yacht. Built for serious cruising, she offers reassuring stability in all conditions, Her generous sail plan delivers excellent light-air performance. Designed for serious cruising, whether coastal hopping or ocean crossings.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 34.000 ft |
| LOA | 36.740 ft |
| LWL | 29.860 ft |
| Beam | 11.320 ft |
| Displacement | 18739 lb |
| Max Draft | 5.740 ft |
The standard boat dimensions
| i | 47.58 ft |
|---|---|
| j | 14.17 ft |
| p | 40 ft |
| e | 14 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 47.58 ft | 14.17 ft | 40 ft | 14 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GENOA |
|---|---|
| Luff | 44.5 ft - (13564 mm) |
| Foot | 23.18 ft - (7065 mm) |
| Leech | 44.83 ft - (13664 mm) |
| Length Perpendicular | 22.47 ft - (6849 mm) |
| Area | 499.88 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 40 ft - (12192 mm) |
| Foot | * 14 ft - (4267 mm) |
| Leech-AftHdBd | * 41.75 ft - (12725 mm) |
| Tack Ang | * 87.98 ° |
| Diag (clew/head) | * 41.91 ft - (12774 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 279.69 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 39.72 ft - (12107 mm) |
| Foot | * 18.56 ft - (5657 mm) |
| Leech | * 34.88 ft - (10631 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 16.3 ft - (4968 mm) |
| Deck Angle | * 12 ° |
| Area | 323.66 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 47.16 ft - (14374 mm) |
| MidGirth | * 25.51 ft - (7775 mm) |
| Foot | * 25.51 ft - (7775 mm) |
| Perc LP | * 180 |
| Area | 1022.59 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
