Coronado 23 Mk Ii
Description
The CORONADO 23 MK II is a sailboat designed by Alan Payne. Her generous sail plan delivers excellent light-air performance.
The standard boat dimensions
| i | 25.83 ft |
|---|---|
| j | 9.15 ft |
| p | 21.58 ft |
| e | 9.25 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 25.83 ft | 9.15 ft | 21.58 ft | 9.25 ft | - | - |
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 21.58 ft - (6578 mm) |
| Foot | * 9.25 ft - (2819 mm) |
| Leech | * 22.99 ft - (7007 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 23.18 ft - (7065 mm) |
| Head (inches) | * 4 in - (102 mm) |
| Area | * 102.91 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 21.92 ft - (6681 mm) |
| Foot | * 12.34 ft - (3761 mm) |
| Leech | * 18.71 ft - (5703 mm) |
| Percentage LP | * 114.97 % |
| Length Perpendicular | * 10.52 ft - (3206 mm) |
| Deck Angle | * 12 ° |
| Area | * 115.31 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 23.5 ft - (7163 mm) |
| Foot | 10 ft - (3048 mm) |
| Leech | 21 ft - (6401 mm) |
| Percentage LP | * 97.6 % |
| Length Perpendicular | * 8.93 ft - (2722 mm) |
| Deck Angle | * 7.2 ° |
| Area | * 104.96 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 26.03 ft - (7934 mm) |
| Foot | * 14.96 ft - (4560 mm) |
| Leech | * 24.31 ft - (7410 mm) |
| Percentage LP | * 149.95 % |
| Length Perpendicular | * 13.72 ft - (4182 mm) |
| Deck Angle | * 3.98 ° |
| Area | * 178.57 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 26.03 ft - (7934 mm) |
| Foot | * 15.1 ft - (4602 mm) |
| Leech | * 23.95 ft - (7300 mm) |
| Perc LP | * 165 % |
| Area | * 295 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 26.03 ft - (7934 mm) |
| MidGirth | * 16.47 ft - (5020 mm) |
| Foot | * 16.47 ft - (5020 mm) |
| Perc LP | * 180 % |
| Area | * 364 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
