Columbia 36 Mk Ii
Description
Length Overall: 36' 2" Length Waterline: 28' 3" Beam: 10' 6" Draft: 5' 3" Displacement: 13,200 lbs. Ballast: 5,000 lbs. Produced from 1969 to 1973
Construction Details
| Designer | Wm Crealock |
|---|---|
| Length | 36.170 ft |
| LOA | 36.170 ft |
| LWL | 27.750 ft |
| Beam | 10.500 ft |
| Displacement | 13200 lb |
| Max Draft | 5.250 ft |
The standard boat dimensions
| i | 41.75 ft |
|---|---|
| j | 15.50 ft |
| p | 34.80 ft |
| e | 14 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 41.75 ft | 15.50 ft | 34.80 ft | 14 ft | - | - |
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 34.8 ft - (10607 mm) |
| Foot | * 14 ft - (4267 mm) |
| Leech | * 36.77 ft - (11207 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 37.05 ft - (11293 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 251.09 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 41.25 ft - (12573 mm) |
| Foot | 20 ft - (6096 mm) |
| Leech | 37 ft - (11278 mm) |
| Percentage LP | * 115.61 % |
| Length Perpendicular | * 17.92 ft - (5462 mm) |
| Deck Angle | * 5.99 ° |
| Area | * 369.62 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 35.63 ft - (10860 mm) |
| Foot | * 21.1 ft - (6431 mm) |
| Leech | * 30.16 ft - (9193 mm) |
| Percentage LP | * 114.97 % |
| Length Perpendicular | * 17.82 ft - (5432 mm) |
| Deck Angle | * 12.01 ° |
| Area | * 317.47 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 42.31 ft - (12896 mm) |
| Foot | * 25.52 ft - (7778 mm) |
| Leech | * 39.38 ft - (12003 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 23.25 ft - (7087 mm) |
| Deck Angle | * 3.99 ° |
| Area | * 491.82 ft² |
| Sail Type | DRIFTER |
|---|---|
| Luff | * 42.31 ft - (12896 mm) |
| Foot | * 26.68 ft - (8132 mm) |
| Leech | * 37.34 ft - (11381 mm) |
| Perc LP | * 150 % |
| Length Perp | * 23.25 ft - (7087 mm) |
| Deck Angle | * 9.01 ° |
| Area | * 491.81 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 42.31 ft - (12896 mm) |
| Foot | * 25.58 ft - (7797 mm) |
| Leech | * 38.93 ft - (11866 mm) |
| Perc LP | * 165 % |
| Area | * 812 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 42.31 ft - (12896 mm) |
| MidGirth | * 27.9 ft - (8504 mm) |
| Foot | * 27.9 ft - (8504 mm) |
| Perc LP | * 180 % |
| Area | * 1003 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 24.49 ft - (7465 mm) |
| Foot | * 12.03 ft - (3667 mm) |
| Leech | * 19.25 ft - (5867 mm) |
| Perc LP | * 60 % |
| Length Perp | * 9.3 ft - (2835 mm) |
| Deck Angle | * 19.02 ° |
| Area | * 113.85 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
