CHESAPEAKE 32
Description
The CHESAPEAKE 32 is a small sailboat designed by Philip Rhodes. With her light displacement hull, she offers spirited performance, featuring variable draft for versatility in different sailing conditions. An ideal choice for weekend cruising, day sailing, or club racing.
Construction Details
| Designer | Philip Rhodes |
|---|---|
| Length | 32.000 ft |
| LOA | 20.000 ft |
| LWL | 15.580 ft |
| Beam | 6.580 ft |
| Displacement | 950 lb |
| Max Draft | 4.420 ft |
| Min Draft | 0.580 ft |
The standard boat dimensions
| i | 36.50 ft |
|---|---|
| j | 12.50 ft |
| p | 32.25 ft |
| e | 14 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 36.50 ft | 12.50 ft | 32.25 ft | 14 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 32.25 ft - (9830 mm) |
| Foot | * 14 ft - (4267 mm) |
| Leech-AftHdBd | * 34.51 ft - (10519 mm) |
| Tack Ang | * 88.01 ° |
| Diag (clew/head) | * 34.71 ft - (10580 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 225.47 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 36.65 ft - (11171 mm) |
| Foot | * 20.35 ft - (6203 mm) |
| Leech | * 34.31 ft - (10458 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 18.75 ft - (5715 mm) |
| Deck Angle | * 4 ° |
| Area | 343.55 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 30.86 ft - (9406 mm) |
| Foot | * 16.75 ft - (5105 mm) |
| Leech | * 26.49 ft - (8074 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 14.38 ft - (4383 mm) |
| Deck Angle | * 12 ° |
| Area | 221.73 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 36.65 |
| MidGirth | * 22.5 ft - (6858 mm) |
| Foot | * 22.5 ft - (6858 mm) |
| Perc LP | * 180 |
| Area | 700.93 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
