Catalina Morgan 381
Description
The Catalina Morgan 381 is a sailboat designed by Charlie Morgan. Her generous sail plan delivers excellent light-air performance.
The standard boat dimensions
| i | 50.50 ft |
|---|---|
| j | 14.67 ft |
| p | 42.17 ft |
| e | 15.67 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 50.50 ft | 14.67 ft | 42.17 ft | 15.67 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 42.17 ft - (12853 mm) |
| Foot | * 15.67 ft - (4776 mm) |
| Leech | * 44.19 ft - (13469 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 44.47 ft - (13554 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 339.38 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 48.25 ft - (14707 mm) |
| Foot | 18 ft - (5486 mm) |
| Leech | 45.67 ft - (13920 mm) |
| Percentage LP | * 116.02 % |
| Length Perpendicular | * 17.02 ft - (5188 mm) |
| Deck Angle | * 2.83 ° |
| Area | * 410.52 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 49.96 ft - (15228 mm) |
| Foot | * 23.44 ft - (7145 mm) |
| Leech | * 47.3 ft - (14417 mm) |
| Percentage LP | * 149.97 % |
| Length Perpendicular | * 22 ft - (6706 mm) |
| Deck Angle | * 3.99 ° |
| Area | * 549.57 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 48.75 ft - (14859 mm) |
| Foot | 20.25 ft - (6172 mm) |
| Leech | 46 ft - (14021 mm) |
| Percentage LP | * 129.86 % |
| Length Perpendicular | * 19.05 ft - (5806 mm) |
| Deck Angle | * 3.66 ° |
| Area | * 464.25 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 49.96 ft - (15228 mm) |
| Foot | * 24.21 ft - (7379 mm) |
| Leech | * 45.96 ft - (14009 mm) |
| Perc LP | * 165 % |
| Area | * 907 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 28.92 ft - (8815 mm) |
| Foot | * 10.77 ft - (3283 mm) |
| Leech | * 24.36 ft - (7425 mm) |
| Perc LP | * 59.99 % |
| Length Perp | * 8.8 ft - (2682 mm) |
| Deck Angle | * 18.99 ° |
| Area | * 127.28 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
