Cape Cod Bull's Eye
Description
The Cape Cod Bull’s Eye is a 15.71-foot trailerable sailboat designed by Nathanael Greene Herreshoff in 1914 and built by Cape Cod Shipbuilding since 1947. Originally constructed in wood as the Herreshoff Bull’s Eye, it evolved into a fiberglass version in 1949, retaining the same hull design but with modern updates. Known for its seaworthiness, stability, and classic design, it’s a popular choice for day sailing and one-design racing.
The standard boat dimensions
| i | 15 ft |
|---|---|
| j | 5 ft |
| p | 19.30 ft |
| e | 10.83 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 15 ft | 5 ft | 19.30 ft | 10.83 ft | - | - |
Documents
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | 19.25 ft - (5867 mm) |
| Foot | 10.83 ft - (3301 mm) |
| Leech | 20.27 ft - (6178 mm) |
| Tack Angle | * 79.25 ° |
| Diagonal | 20.25 ft - (6172 mm) |
| Head (inches) | 4 in - (102 mm) |
| Area | * 105.78 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 14.167 ft - (4318 mm) |
| Foot | 4.83 ft - (1472 mm) |
| Leech | 12.42 ft - (3786 mm) |
| Percentage LP | * 83.2 % |
| Length Perpendicular | * 4.16 ft - (1268 mm) |
| Deck Angle | * 12.22 ° |
| Area | * 29.43 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 14.5 ft - (4420 mm) |
| Foot | 8.5 ft - (2591 mm) |
| Leech | 13.83 ft - (4215 mm) |
| Percentage LP | * 158 % |
| Length Perpendicular | * 7.9 ft - (2408 mm) |
| Deck Angle | * 3.29 ° |
| Area | * 57.25 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | 17.167 ft - (5233 mm) |
| MidGirth | 12 ft - (3658 mm) |
| Foot | 12 ft - (3658 mm) |
| Perc LP | * 180 % |
| Area | * 175 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
