Bristol 32
Description
The Bristol 32 is a classic fiberglass sailboat designed by Ted Hood (with contributions from Dieter Empacher) and built by Bristol Yachts in Rhode Island from 1966 to 1983, with approximately 322 units produced. It's a heavy-displacement, full-keel cruiser renowned for its seaworthiness, solid construction, and blue water capabilities, often described as a "tank" that prioritizes safety and stability over speed.
Construction Details
| Designer | Hood, Ted |
|---|---|
| Builder | Bristol Yachts |
| Length | 32.000 ft |
| LOA | 32.000 ft |
| LWL | 22.000 ft |
| Beam | 9.500 ft |
| Displacement | 10800 lb |
| Max Draft | 4.670 ft |
The standard boat dimensions
| i | 40 ft |
|---|---|
| j | 12.58 ft |
| p | 35.10 ft |
| e | 13.70 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 40 ft | 12.58 ft | 35.10 ft | 13.70 ft | - | - |
Blueprints
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 35.1 ft - (10698 mm) |
| Foot | * 13.7 ft - (4176 mm) |
| Leech | * 36.9 ft - (11247 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 37.23 ft - (11348 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 247.25 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 33.55 ft - (10226 mm) |
| Foot | * 16.62 ft - (5066 mm) |
| Leech | * 29.21 ft - (8903 mm) |
| Percentage LP | * 115.02 % |
| Length Perpendicular | * 14.47 ft - (4410 mm) |
| Deck Angle | * 12.01 ° |
| Area | * 242.73 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 39.83 ft - (12140 mm) |
| Foot | * 20.28 ft - (6181 mm) |
| Leech | * 37.49 ft - (11427 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 18.87 ft - (5752 mm) |
| Deck Angle | * 4.05 ° |
| Area | * 375.76 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 39.83 ft - (12140 mm) |
| Foot | * 20.76 ft - (6328 mm) |
| Leech | * 36.64 ft - (11168 mm) |
| Perc LP | * 165 % |
| Area | * 620 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 39.83 ft - (12140 mm) |
| MidGirth | * 22.64 ft - (6901 mm) |
| Foot | * 22.64 ft - (6901 mm) |
| Perc LP | * 180 % |
| Area | * 766 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 23.06 ft - (7029 mm) |
| Foot | * 9.39 ft - (2862 mm) |
| Leech | * 19.04 ft - (5803 mm) |
| Perc LP | * 60.02 % |
| Length Perp | * 7.55 ft - (2301 mm) |
| Deck Angle | * 19.01 ° |
| Area | * 87.06 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
