AMERICAN 2+2
Description
The AMERICAN 2+2 is a small sailboat designed by American Mariner Industries. She strikes a balance between performance and comfort, Her generous sail plan delivers excellent light-air performance. An ideal choice for weekend cruising, day sailing, or club racing.
Construction Details
| Designer | American Mariner Industries |
|---|---|
| Length | 17.000 ft |
| LOA | 20.750 ft |
| LWL | 17.670 ft |
| Beam | 7.830 ft |
| Displacement | 2500 lb |
| Max Draft | 2.170 ft |
The standard boat dimensions
| i | 20 ft |
|---|---|
| j | 6.50 ft |
| p | 19.75 ft |
| e | 8.30 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 20 ft | 6.50 ft | 19.75 ft | 8.30 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GENOA |
|---|---|
| Luff | 19.98 ft - (6090 mm) |
| Foot | * 10.52 ft - (3206 mm) |
| Leech | * 18.76 ft - (5718 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 9.75 ft - (2972 mm) |
| Deck Angle | * 4.06 ° |
| Area | * 97.4 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 19.75 ft - (6020 mm) |
| Foot | * 8.3 ft - (2530 mm) |
| Leech-AftHdBd | * 20.99 ft - (6398 mm) |
| Tack Ang | * 87.97 ° |
| Diag (clew/head) | * 21.15 ft - (6447 mm) |
| Head (inches) | * 3.5 in |
| Area (no Roach) | * 84.48 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 17.25 ft - (5258 mm) |
| Foot | 7.5 ft - (2286 mm) |
| Leech | 15 ft - (4572 mm) |
| Percentage LP | * 100 % |
| Length Perpendicular | * 6.5 ft - (1981 mm) |
| Deck Angle | * 11.85 ° |
| Area | * 56.1 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 20 ft - (6096 mm) |
| Foot | 11 ft - (3353 mm) |
| Leech | 18.5 ft - (5639 mm) |
| Perc LP | * 165 |
| Area | * 165 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
